🧩 Services

This section provides a complete overview of all services included in the CogStack-NiFi deployment.
All services run in Docker and interact within a shared internal Docker network.

πŸ“Š Overview

Below is a high-level architecture diagram illustrating how CogStack services communicate when all components are enabled:

nifi-services

🧩 Primary Services

The core services defined in services.yml include:

  • samples-db β€” PostgreSQL database populated with demo datasets.

  • cogstack-databank-db / cogstack-databank-db-mssql β€” Production-grade PostgreSQL and optional MSSQL instances.

  • elasticsearch-1 / elasticsearch-2 / elasticsearch-3 β€” Multi-node Elasticsearch or OpenSearch cluster.

  • metricbeat / filebeat β€” Elastic monitoring and log forwarder services.

  • nifi β€” Apache NiFi single-node instance with embedded ZooKeeper.

  • nifi-nginx β€” Reverse proxy providing secure access to NiFi.

  • ocr-service / ocr-service-text-only β€” High-performance Python OCR and text extraction services.

  • nlp-medcat-service-production β€” MedCAT NLP model service with REST API.

  • medcat-trainer-ui / medcat-trainer-nginx β€” Web UI and reverse proxy for model training and refinement.

  • kibana β€” OpenSearch Dashboards UI.

  • jupyter-hub β€” Fully featured data science interface.

  • git-ea β€” Self‑hosted Git service (Gitea).

πŸ” Note: Important configuration options and environment variables for these services are managed in services.yml and the associated .env files under deploy/ and security/.

πŸ—‚οΈ Service Definitions

All core services are defined in:

deploy/services.yml

They run inside the internal Docker network cognet.
Some services expose ports to the host for convenience.

πŸ—£οΈ NLP/OCR and other services API Endpoints

Most web ETL & data-enrichment API services that we use will offer thw following endpoints for querying.

  • GET /api/info

  • POST /api/process

  • POST /api/process_bulk

Useful for NiFi workflows (see workflows.md).

🧬 MedCAT Service

Runs a REST API for model inference uses the MedCAT library which performss clinical concept extraction and linking.

The service has two operation modes:

  • concept detection: exctracts medical concepts: outputs original text + annotations list.

  • de-id mode aka. AnonCAT mode, for de-identifying documents: outputs de-identified text + (will output annotations that represent what was de-id in a future version).

Access

  • https://localhost:5555/api/info - NER container, check if model loads successfully

  • https://localhost:5556/api/info - DE-ID/AnonCAT container

Containers

  • cogstack-medcat-service-production - for concept NER

  • cogstack-medcat-service-production-deid - for DE-ID/AnonCAT

Service location & files

  • dir: /services/cogstack-nlp/medcat-service/

  • docker compose file: /services/cogstack-nlp/medcat-service/docker/docker-compose.yml

  • env: located in services/cogstack-nlp/medcat-service/env/

        app.env - controls APP settings (number of cpus used, log level, etc) used by the NER container cogstack-medcat-service-production
    medcat.env - used by the NER container, controls MedCAT settings directly.
    app_deid.env - used by the DE-ID container, same app setting control, the main difference being the `APP_DEID_MODE`.
    medcat_deid.env  - used by the DE-ID container, controls MedCAT settings directly

Ports

Service

External Port

Internal Port

NER (MedCAT)

5555

5000

DE-ID / AnonCAT

5556

5000

Models

  • A default MedMentions MedMen NER+L model (includes MetaCAT models) is available for public use but needs to be downloaded.

  • To download a model head to the directory of the service services/cogstack-nlp/medcat-service/scripts

  • Execute: bash download_medmen.sh, wait for download to complete.

README

Please check the service’s own README.md

πŸ› οΈ MedCAT Trainer

Provides UI workflows for annotation, correction, and iterative model training.

Access

  • https://localhost:8001

Containers

  • medcattrainer

  • medcattrainer_nginx

  • mct_solr

Service location & files

  • dir: services/cogstack-nlp/medcat-trainer/

  • docker compose file: services/cogstack-nlp/medcat-trainer/docker-compose-prod.yml

  • env: services/cogstack-nlp/medcat-trainer/envs/env-prod

Ports

  • external: 8001

README

Please check the service’s own README.md file and docs.

πŸ“š Jupyter Hub

A multi-user JupyterHub instance deployed via Docker.

Access

  • https://localhost:8888

Containers

  • cogstack-jupyter-hub

  • cogstack-jupyter-singleuser-<USERNAME> (per user container started by each user once hub is up)

Service location & files

  • dir: services/cogstack-jupyter-hub/

  • docker compose file: services/cogstack-jupyter-hub/docker/

  • env: services/cogstack-jupyter-hub/env/jupyter.env

Supports

  • Per-user containers

  • CPU/RAM limits (via services/cogstack-jupyter-hub/env/jupyter.env)

  • Optional GPU support

  • Notebook image selection

Ports

Component

External Port

Internal Port(s)

JupyterHub

8888

8087, 443

README

Please check the service’s own README.md file.

πŸ§ͺ Samples DB (PostgreSQL)

Demo dataset with:

  • patients

  • encounters

  • observations

  • raw medical reports

  • cleaned reports

  • annotation tables

Acess

  • localhost:5555

Ports

  • external: 5432

  • internal: 5432

Credentials

  • user - test, password - test

🏦 Cogstack databank production DB (Production only: PgSQL, MSSQL)

Empty database for production ingestion pipelines.
Supports both PostgreSQL and MSSQL.

Place schema files inside and they will be loaded instantly on container startup:

services/cogstack-db/<DB_PROVIDER>/schemas/

Where <DB_PROVIDER> can be: mssql,pgsql.

Credentials

  • PgSQL: user - admin password - admin

  • MsSQL: user - admin password - admin!COGSTACK2022

Access

  • PgSQL: localhost:5558 β†’ container 5432

  • MSSQL: localhost:1443 β†’ container 1433

Containers

  • PgSQL: cogstack-databank-db

  • MSSQL: cogstack-databank-db-mssql

Service location & files

  • docker compose file: services.yml

  • dir: services/cogstack-db/

  • env:

    • security/users/users_database.env - controlers DB user credentials

    • deploy/database.env - general DB configs

Ports

Database

External Port

Internal Port

PgSQL

5558

5432

MSSQL

1433

1433

πŸ’§ Apache NiFi

Primary ETL/processing engine.

This service is complex and is completely described in this section.

Credentials

  • Default user: user - admin password - cogstackNiFi

Access

https://localhost:8443 (via nifi-nginx)

Containers

  • NiFi: cogstack-nifi

Service location & files

  • docker compose file: services.yml

  • dir: nifi/

  • env:

    • /deploy/nifi.env - general NiFi settings, JVM memory, etc.

    • /security/nifi_users.env - controlers DB user credentials

    • /security/certificates_nifi.env

Ports

Component

External Port

Internal Port

NiFi

8443

8082, 10000

πŸ”Ž ELK Stack (Elasticsearch / OpenSearch)

Backend search and indexing engine powering document storage, query, analytics, and NLP output retrieval.

This service is fully described in the Elasticsearch section of the documentation.

The repo supports both:

  • ElasticSearch (native)

  • OpenSearch (Amazon fork)

Switch between modes via environment variables in deploy/elasticsearch.env.

πŸ›’οΈ Elasticsearch / OpenSearch

Credentials

  • OpenSearch: user - admin, password - admin

  • ElasticSearch: user - elastic, password - kibanaserver

Access

  • http://localhost:9200 β€” Node 1

  • http://localhost:9201 β€” Node 2

  • http://localhost:9202 β€” Node 3

Containers

  • elasticsearch-1

  • elasticsearch-2

  • elasticsearch-3

Ports

  • all ports need to be exposed via firewall to allow for intercluster communication, we assume 1 different port per node if hosted on the same machine/VM, in production mode all machines can have and use the following ports (if they live on separarate VMs/machines ): 9200, 9300, 9600

  • internal: 9300, 9301, 9302, 9600, 9601, 9602, 9200, 9201, 9202

  • external: 9300, 9301, 9302, 9600, 9601, 9602, 9200, 9201, 9202

Node

HTTP

Transport

Analyzer

ES1

${ELASTICSEARCH_NODE_1_OUTPUT_PORT:-9200}

${ELASTICSEARCH_NODE_1_COMM_OUTPUT_PORT:-9300}

${ELASTICSEARCH_NODE_1_ANALYZER_OUTPUT_PORT:-9600}

ES2

${ELASTICSEARCH_NODE_2_OUTPUT_PORT:-9201}

${ELASTICSEARCH_NODE_2_COMM_OUTPUT_PORT:-9301}

${ELASTICSEARCH_NODE_2_ANALYZER_OUTPUT_PORT:-9601}

ES3

${ELASTICSEARCH_NODE_3_OUTPUT_PORT:-9202}

${ELASTICSEARCH_NODE_3_COMM_OUTPUT_PORT:-9302}

${ELASTICSEARCH_NODE_3_ANALYZER_OUTPUT_PORT:-9602}

Service Location & files

  • docker compose: deploy/services.yml

  • config: services/elasticsearch/config/

  • env:

    • /deploy/elasticsearch.env

    • /security/certificates_elasticsearch.env

    • /security/elasticsearch_users.env

SSL & Certificates

Certificates stored in:

/security/certificates/elastic/<ELASTICSEARCH_VERSION>/

Settings in:

  • certificates_elasticsearch.env

πŸ“Š Metricbeat & Filebeat

Lightweight Elastic stack agents used for monitoring and log forwarding.
They run alongside Elasticsearch to provide observability of the cluster and ingestion pipelines.

Purpose:

  • Metricbeat β€” collects system & Elasticsearch metrics (CPU, memory, JVM, node health).

  • Filebeat β€” ships container and service logs into Elasticsearch.

Both run as independent containers in the deployment.

Containers

Metricbeat:

  • metricbeat-1

  • metricbeat-2

  • metricbeat-3

Filebeat:

  • filebeat-1

  • filebeat-2

  • filebeat-3

Service Location & Files

  • compose: deploy/services.yml

  • config:

    • services/metricbeat/metricbeat.yml

    • services/filebeat/filebeat.yml

  • env:

    • /deploy/elasticsearch.env

    • /security/elasticsearch_users.env

Ports

No external ports exposed.
All communication occurs internally within the cogstack-net Docker network.

Notes

  • Elasticsearch must be running before Metricbeat or Filebeat start.

  • Only Elastic-native Beats are available; OpenSearch-native Beats do not exist.

  • Authentication/credentials come from elasticsearch_users.env.

πŸ“‰ Kibana / OpenSearch Dashboards

Web UI for exploring indexed data, visualising documents, managing index templates, monitoring the cluster, and debugging ingestion pipelines.

Purpose:

  • Search & browse Elasticsearch/OpenSearch indices

  • Visualise ingestion outputs and cluster metrics

  • Manage index patterns, dashboards, and Dev Tools

  • Validate mappings and test queries used in NiFi flows

Host Access

  • URL: https://localhost:5601

credentials

  • OpenSearch Dashboards: admin / admin

  • Elasticsearch Native: elastic / kibanaserver

Containers

  • cogstack-kibana (OpenSearch Dashboards or Kibana depending on configuration)

Service Location & Files

  • docker compose: deploy/services.yml

  • config files:

    • services/kibana/config/elasticsearch.yml (Elasticsearch)

    • services/kibana/config/opensearch.yml (OpenSearch Dashboards)

  • env:

    • /deploy/elasticsearch.env

    • /security/certificates_elasticsearch.env

    • /security/elasticsearch_users.env

Image selection controlled by:

  • ${ELASTICSEARCH_KIBANA_DOCKER_IMAGE}

  • ${KIBANA_VERSION}

  • ${KIBANA_CONFIG_FILE_VERSION}

Ports

Component

External

Internal

Kibana / OpenSearch Dashboards

5601

5601

Notes

  • Must be started after Elasticsearch/OpenSearch

  • Connects automatically using ELASTICSEARCH_HOSTS

  • TLS/user settings are applied from the /security env files

πŸ€– OCR Service

High-performance document text extraction engine replacing legacy Tika for OCR + text processing. In the near future it will be possible to use LLMs/custom models for ocr-ing (pending v2 release, ETA 2026).

The service comes in two variants:

  • ocr-service β€” full OCR pipeline (images β†’ text)

  • ocr-service-text-only β€” lightweight mode (text extraction only, no OCR)

Both expose a simple REST API.

Purpose:

  • Extract text from PDFs, images, and scanned documents

  • Provide OCR via Tesseract (wrapped in optimised Python service)

  • Provide fast plain text extraction for digital PDFs (text-only variant)

  • Designed for large-scale throughput within NiFi ingestion pipelines

Access

  • ocr-service: http://localhost:8090/api/process

  • ocr-seervice-text-only: http://localhost:8091/api/process

Containers

  • ocr-service

  • ocr-service-text-only

Both built from:

cogstacksystems/cogstack-ocr-service:<release>

Service Location & Files

  • docker compose file: services/ocr-service/docker/docker-compose.yml

  • service directory: services/ocr-service/

  • logs:

    • Host: services/ocr-service/log/

    • Container: /ocr_service/log/

  • env files:

    • deploy/general.env β€” shared variables

    • services/ocr-service/env/ocr_service.env β€” full OCR config

    • services/ocr-service/env/ocr_service_text_only.env β€” overrides for text-only pipeline

Ports

Service

External

Internal

ocr-service

8090

8090

ocr-service-text-only

8091

8090

Both expose the API internally on port 8090.

Please check the service’s own README.md

πŸ—‚οΈ Git-ea

Self-hosted Git instance (Gitea). Lightweight GitHub/GitLab-style service used for hosting repositories inside secure or offline environments.

Purpose:

  • Internal code hosting for organisations without external Git access

  • Repository management, issue tracking, wiki, and basic CI hooks

  • Ideal for notebooks, configs, workflows, and internal project code

Access

  • URL: http://localhost:3000 (default Gitea port)

Containers

  • gitea

Service Location & Files

  • docker compose file: deploy/services.yml

  • config file: services/gitea/app.ini

  • env files:

    • /security/certificates_general.env

Persistent repository data is stored in the volume defined in services.yml.

Ports

Service

External

Internal

Git-ea

3000

3000

Notes

  • Supports repository migration from external Git servers

  • Mirroring available when external access is allowed

  • Can use CogStack certificates for HTTPS if configured

🧱 NGINX

Note: this component may eventually be replaced by Traefik as the preferred reverse‑proxy and ingress layer for CogStack deployments.

NGINX is used as a lightweight reverse proxy to provide secure, unified access to internal CogStack services.
It handles HTTPS, routing, and access control for NiFi, MedCAT Trainer, and other components.

MedCAT-Trainer has its own nginx instance that runs independently.

Purpose:

  • Secure external access to internal services

  • Reverse proxy for NiFi, MedCAT Trainer, and service UIs

  • TLS termination (optional)

  • Basic auth / access control where required

Two variants are included:

  • nginx-nifi β€” main proxy for NiFi and related services

  • nginx-medcat-trainer β€” specialized proxy for MedCAT Trainer

Two variants:

  • nginx-nifi β€” main proxy for services

  • nginx-medcat-trainer β€” dedicated trainer proxy

Access

Examples (actual paths depend on config):

  • NiFi: https://localhost:8443

  • MedCAT Trainer: https://localhost:8001

Routing rules are defined in the NGINX configuration files.

Containers

  • nifi-nginx β€” main proxy for NiFi

  • medcat-trainer-nginx β€” proxy dedicated to MedCAT Trainer

Service Location & Files

  • docker compose file: deploy/services.yml, trainer - deploy/cogstack-nlp/medcat-trainer

  • config files:

    • services/nginx/config/nifi.conf

    • services/nginx/config/medcat-trainer.conf

    • additional templates under services/nginx/config/

  • env / certificates:

    • /security/certificates_general.env

    • /security/certificates_nifi.env

  • Uses shared CogStack Root CA & NiFi certs (root-ca.p12, root-ca.key, nifi.key, nifi.pem)

Port

Proxy Target

External

Internal

NiFi

8443

8443

Notes

  • Provides HTTPS entrypoints for internal services

  • Works with CogStack certificate bundle

  • Trainer uses a separate NGINX instance for routing differences

  • Modify NGINX configs only if comfortable with its syntax
